Rhino 7.0 Designing Software

Rhino can create, edit, analyze, document, render, animate, and translate NURBS curves, surfaces and solids, subdivision geometry (SubD), point clouds, and polygon meshes. There are no limits on complexity, degree, or size beyond those of your hardware.

Special features include:

• Uninhibited free-form 3D modeling tools like those found only in products costing 20 to 50 times more. Model any shape you can imagine.
• Accuracy needed to design, prototype, engineer, analyze, and manufacture anything from an airplane to jewelry.
• Compatibility with all your other design, drafting, CAM, engineering, analysis, rendering, animation, and illustration software.
• Read and repair meshes and extremely challenging IGES files.
• Accessible. So easy to learn and use that you can focus on design and visualization without being distracted by the software.
• Fast, even on an ordinary laptop computer. No special hardware is needed.
• Development platform for hundreds of specialty 3D products.
• Affordable. Ordinary hardware. Short learning curve. Affordable purchase price. No maintenance fees.
• Rhino for Mac: The world’s most versatile 3D modeler, available on macOS.

New in Rhino 7

Rhino 7 is the most significant upgrade in our history. Create organic shapes with our new SubD tools. Run Rhino and Grasshopper as a Revit® Add-On with Rhino.Inside.Revit. Use the robust QuadRemesh algorithm to create a beautiful quad mesh from NURBS geometry or meshes. With this release, we’ve unlocked completely new modeling workflows and refined many steadfast features.

Thanks to thousands of prerelease users, we were able to field test and refine Rhino 7, making it the fastest and most stable version ever.

Model Creation Tools

Points: Points, point clouds, point grid, extract from objects, mark (intersection, divide, draft-angle, ends, closest, foci).

Curves: Line, polyline, polyline on mesh, free-form curve, circle, arc, ellipse, rectangle, polygon, helix, spiral, conic, TrueType text, point interpolation, control points (vertices), sketch.

Curves from other objects: Through points, through polyline, extend, continue curve, fillet, chamfer, offset, blend, arc blend, from two views, tween, cross-section profiles, intersection, contour on NURBS surface or mesh, section on NURBS surface or mesh, border, silhouette, extract isoparm, extract curvature graph, projection, pullback, sketch, wireframe, detach trim, 2D drawings with dimensions and text, flatten developable surfaces.

Surfaces: From 3 or 4 points, from 3 or 4 curves, from planar curves, from network of curves, rectangle, deformable plane, extrude, ribbon, rule, loft with tangency matching, developable, sweep along a path with edge matching, sweep along two rail curves with edge continuity, revolve, rail revolve, tween, blend, patch, drape, point grid, heightfield, fillet, chamfer, offset, plane through points, TrueType text, Unicode (double-byte) text.

Solids: Box, sphere, cylinder, tube, pipe, cone, truncated cone, pyramid, truncated pyramid, ellipsoid, torus, extrude planar curve, extrude surface, cap planar holes, join surfaces, region, nonmanifold merge, TrueType text, Unicode (double-byte) text.

Meshes: From NURBS surfaces, from closed polyline, mesh face, plane, box, cylinder, cone, and sphere.

Rhino 7 adds dozens of refinements to existing tools and some new commands:

• SubD: For designers who need to explore organic shapes quickly, SubD is a new geometry type that can create editable, highly accurate shapes. Unlike other geometry types, SubD combines free-form accuracy while still allowing quick editing.
• BlendSrf: New Refine checkbox avoids creating a simpler blend surface.
• Revolve: Ends of the revolving axis can be attached to objects using object snaps when History is recorded.
• MatchSrf: History locking allows editing control points of matched surfaces.
• DupBorder: Added History support.
• FilletSrf: Now has a G2 option.
