Heavy-duty dual motor station for intensive polishing.
Related Products
Romanoff White Metal Casting Kit
$19,974.00
Romanoff Pickle Pot
$296.20
| Specification | 87-009 | Z42-366-C | Z42-366-D |
|---|---|---|---|
| Product | Polishing Station with ½ HP Dust Collector and ¾ HP Single-Spindle Polishing Motor | Dual Spindle & Hood ½ HP Open Polishing Station with 1 HP Dust Collector | Double ¾ HP Single Spindle & Hood Polishing Station with 1 HP Dust Collector |
| SKU# | 87-009 | Z42-366-C | Z42-366-D |
| Suction Motor | 1/2 HP | 1 HP | 1 HP |
| Polishing Motor | 3/4 HP | 1/2 HP | Double 3/4 HP single spindle |
| Air Flow | 400 CFM | 1,000 CFM | 1,000 CFM |
| Electrical | 110 V, 9A, 1 Ph, 60Hz | 110V, 9A, 1 Ph, 60Hz | 110V, 9A, 1Ph, 60Hz |
| Stations | One Station, One Auxiliary | Two | Two |
| Replacement Bag / Filter | Replacement Bag # 87-010A | Replacement Bag # 87-010A | Replacement Filter # Z42-009-H2 |
| Hood Light Source | Illuminated | Illuminated | — |
| Noise Level | 50 dB | 63 dB | 63 dB |
| Overall Dimensions (W x D x H) | 24 x 24 x 48 in. (609 x 609 x 1219 mm) |
48 x 24 x 56 in. (1219 x 609 x 1422 mm) |
48 x 24 x 56 in. (1219 x 609 x 1422 mm) |
| Table Top Dimensions (W x D) | 24 x 24 in. (609 x 609 mm) |
48 x 24 in. (1219 x 609 mm) |
48 x 24 in. (1219 x 609 mm) |
| Hood Dimensions (L x W x H) | 12.75 x 16 x 15 in. (323.85 x 406 x 381 mm) |
14 x 16 x 16 in. (355 x 406 x 406 mm) |
— |
| Shipping / Machine Weight | 150 lbs. (68 kg) |
229 lbs. (103 kg) |
229 lbs. (103.9 kg) |
This unique configuration pairs a high-horsepower motor with a single-spindle hood, focusing 100 percent of the suction and torque on one workstation. It is designed for heavy-duty applications that generate significant amounts of dust and require maximum motor "push" behind the wheel. The hood is engineered to wrap around the spindle, ensuring that virtually all metal loss is captured for the refining cycle. It is an ideal setup for specialized tasks like heavy watch case polishing or large-scale metal fabrication.
| Specifications | |
|---|---|
| Brand | Romanoff |
| Suction Motor | 1 HP |
| Air Flow | 1,000 CFM |
| Electrical | 110V, 9A, 1Ph, 60Hz |
| Stations | Two |
| Filter | 24 cloth bags 19" x 9.5", totaling 90 sq. ft. |
| Replacement Filter # | Z42-009-H2 |
| Filter Shakedown | External foot pedal; removable catch pan |
| Noise Level | 63 dB |
| Dimensions (W x D x H) | 48"W x 24"D x 56"H (1219 x 609 x 1422mm) |
| Table Top Dimensions (W x D) | 48"W x 24"D (1219 x 609mm) |
| Shipping Weight | 229 lbs. (103.9kg) |
