The Super Blue automatic furnace with touch screen controller (12" × 81⁄2" × 9") is a high-precision melting and thermal processing system that combines dependable heating performance with intuitive digital control. Its touch screen interface simplifies programming and monitoring, making it suitable for jewelry, metalworking, laboratory, and precision heat-treating applications.
Product Manual
Romanoff Super Blue: Professional Manual & Automatic Furnaces
The Romanoff Super Blue series represents a versatile heating solution engineered for precision enameling, glass jewelry, ceramics, and professional lost wax casting. This model features a generous 12" x 8.5" x 9" internal chamber, utilizing 2.5" thick insulating firebricks for exceptional heat retention and controlled cooling cycles. Designed with a built-in cool-touch base and a specialized top vent for casting, the Super Blue series balances industrial-grade performance with a compact, user-friendly design.
Industrial Engineering & Durability
Every component of the Super Blue is refined for longevity, from the protected sensors to the high-temperature wiring architecture.
- Protected Thermocouples: Sheathed in high-nickel stainless steel to ensure a long service life and accurate temperature readings.
- Exposed Element Design: Heating elements are housed in recessed firebrick grooves for maximum heat transfer and effortless replacement.
- Premium Internal Wiring: Features nickel-copper wire with high-temperature glass braided insulation and heat-dissipating connectors.
- Ergonomic Operation: Features a single-hand door latch and a built-in safety switch that automatically cuts power to elements when opened.
Sentry Xpress Digital Controller
The automatic models come equipped with a sophisticated base-mounted controller for total thermal management.
- Multi-Segment Programming: Design programs with up to 8 segments in Ramp-Hold or Single Speed modes (Fahrenheit or Celsius).
- Dynamic Firing Adjustments: Change target temperatures, add hold times, or skip segments mid-firing without restarting the program.
- Precision Alerts: Programmable temperature alarms and error messaging for thermocouple or relay diagnostics.
- Delayed Firing: Integrated delay timer allows you to schedule kiln operation to suit your production workflow.
Technical Performance Specs
| Process | Furnace Advantage |
|---|---|
| Lost Wax Casting | Tapered top vent plug for specialized burnout cycles. |
| Glass & Enameling | Slow cooling firebricks optimized for the annealing range. |
| Jewelry & Ceramics | High-torque Ramp-Hold programs with 8-segment control. |
Coast to Coast Support: Backed by Romanoff International’s extensive technical network, ensuring your high-production casting line remains operational with expert service and training across the country.
| Specifications | |
|---|---|
| Voltage | 110 V/220 V |
| Temperature Max | 2000°F |
| Fire Chamber Opening (L x W x H) | 12 x 8 x 9 in |
| Amps | 19 |
| Watts | 2280 W |
| Outside Dimensions (L x W x H) | 22 x 14 x 17 |
| Weight | Uncrated: 70 lbs Crated: 80 lbs |
